Silicon aluminum (GL) alloy, as the name implies, is an alloy composed of silicon and aluminum. The alloy has many excellent properties such as controllable thermal expansion coefficient, light weight, good thermal conductivity, dimensional stability, high rigidity and strong machinability. It is precisely because of its unique properties that it has been widely used in military and civilian important components such as radar, communications, sensors, power systems and circuit board brackets.
Get A Quote

Core Technology

Independent research and development of core technology, to ensure product advancement and high performance quality

Professional Team

Professional R & D team to ensure the advantages of technology in the industry market

Special Custom

According to the industry attributes to provide customers with exclusive customized services

Rapid After-sales

Perfect service mechanism, to provide you with the best product plan and after-sales support

about us

We Have The Best Solutions for Your Business

Tianjin Zuoyuan New Material Technology Co., Ltd. is a high-tech company specializing in advanced metal material preparation technology research and high-performance metal material development, production and sales. Mainly produces high-silicon aluminum alloy and superhard aluminum alloy, including alloy raw materials, bars, pipes, plates, profiles and so on. Widely used in aerospace, aviation, electronics, automotive, machinery and petroleum industry and other sophisticated fields.

Learn More

Definition of silicon aluminum alloy

High-silicon aluminum alloy is a binary alloy composed of silicon and aluminum, which is a metal-based thermal management material. High silicon aluminum alloy material can maintain the excellent properties of silicon and aluminum, and the content of silicon and aluminum is quite rich. The density of high-silicon aluminum alloy is between 2.4 and 2.7 g/cm³, and the coefficient of thermal expansion (CTE) is between 7-20ppm/℃. Increasing the silicon content can significantly reduce the density and thermal expansion coefficient of the alloy material. At the same time, high silicon aluminum alloy also has good thermal conductivity, high specific strength and rigidity, good plating performance with gold, silver, copper, nickel, weldability with substrates, easy precision machining, etc. It is a promising electronic packaging material, especially in high-tech fields such as aerospace, space technology and portable electronic devices.
The preparation methods of high silicon aluminum alloy composite materials mainly include the following: 1. Smelting and casting; 2. Infiltration method; 3. Powder metallurgy; 4. Vacuum hot pressing method; 5. Rapid cooling/spray deposition method.

Definition of silicon aluminum alloy

What is the use of silicon aluminum alloy?

In the steelmaking process, both aluminum and ferrosilicon are strong deoxidizers, but aluminum has a low density, low melting point, and is easy to oxidize. Due to its high density and high melting point, ferro-aluminum is easy to sink into molten steel, so its utilization rate can reach 70%. The traditional method of smelting ferrosilicon and aluminum is obtained by melting ferrosilicon and aluminum, which consumes a large amount of aluminum and has high cost. The submerged arc furnace method uses bauxite as the main raw material, which has wide resources and low price, and has broad development prospects.

What is the use of silicon aluminum alloy?

The use of aluminum silicon alloy

Aluminum-silicon alloys have the following uses:
1. In aluminum-silicon alloys whose silicon content exceeds the Al-Si eutectic point (silicon 11.7%), silicon particles can significantly improve the wear resistance of the alloy, forming a class of wear-resistant alloys with a wide range of uses.
2. It is used to manufacture low and medium strength castings with complex shapes, such as cover plates, motor casings, brackets, etc., and is also used as brazing solder.
3. Aluminum-silicon alloy is a kind of strong composite deoxidizer. It can improve the utilization rate of deoxidizer by replacing pure aluminum in the steelmaking process, and can purify molten steel and improve the quality of steel. Ingots deoxidized with aluminum are generally called stabilized steels. Since aluminum is deoxidized and oxidized into alumina, alumina can refine austenite grains, so aluminum deoxidized steels have better comprehensive mechanical properties.
4. Silicon aluminum alloy has low density, low thermal expansion coefficient, good casting performance and anti-wear performance. The alloy castings cast with it have high impact resistance and good high pressure compactness, which can greatly improve the service life. Spacecraft and auto parts.

The use of aluminum silicon alloy
User Reviews

What users say about Us

We have been sourcing high-silicon aluminum alloy from Tianjin Zuoyuan for several years now, and their consistently top-notch quality has been instrumental in our aerospace projects. Their dedication to precision and reliability sets them apart in the industry.

Jovan

The superhard aluminum alloy products from Tianjin Zuoyuan have truly exceeded our expectations. We rely on their materials for our cutting-edge electronics manufacturing, and they've never let us down. Excellent products and exceptional service!

Thiago

Tianjin Zuoyuan's high-silicon aluminum alloy products have played a pivotal role in our advanced machinery manufacturing. Their consistency in delivering high-quality materials and their attention to detail make them our go-to supplier.

Cassian

As a leading player in the petroleum industry, we demand the best materials, and Tianjin Zuoyuan consistently delivers. Their superhard aluminum alloy products have improved our drilling operations significantly, and their partnership approach is truly valued.

Soraya
Frequently Asked Question

Do you have any question?

Tianjin Zuoyuan New Material Technology Co., Ltd. is a high-tech company specializing in the research of advanced metal material preparation technology and the development, production and sales of high-performance metal materials. With the valuable experience accumulated over the years in the field of non-ferrous metal development and the integration of advanced automation control technology, Zhongyuan has achieved remarkable results in the field of high-performance metal materials and has become an innovative enterprise with strong competitiveness in this field. The superhard aluminum alloys and high wear-resistant aluminum alloys developed by the company have been successfully applied in high-end fields such as aerospace, satellite communications, and auto parts industries.

We have a rapid solidification process, which is further optimized on the basis of the spray molding process (also known as spray deposition), which is similar to the atomization pulverization process, which sprays molten, atomized metal onto a rotating substrate , the metal forming process of forming metal ingots or billets. . This process has a high solidification rate and a relative density of over 99.2%. After hot working (forging, rolling, extrusion or HIP), the material is processed into a dense product.

Yes. All AlSi alloys can be machined easily, such as CNC, EDM, wire cutting etc.
